Stuv 16-up 16/78 Wood Burning Stove

The Stûv 16-Up 16/78 is a striking elevated stuv wood burner designed for maximum flame presence and heating power, combining large log capacity with modern aesthetic integration.

£4,918.80 inc. VAT

Order Stove Install quote

*Pay safely with credit card.

Made By:
Stuv

Designed as: Woodburner

Sold by
Hot Box

Order Stuv 16-up 16/78 Wood Burning Stove

Description

The Stûv 16-Up 16/78 takes the boldest dimensions in the 16-series and elevates them — mounting the firebox higher to bring dramatic flames into eye level. With capacity for longer logs (≈ 60 cm), this stove delivers a sweeping visual impact in large rooms or open-plan spaces, positioning the fire as a focal point rather than a background accent.

Its raised configuration gives the flame a floating, architectural feel, while the exterior remains clean and refined — no exposed handles, vents, or visual clutter. The wide viewing pane lets you fully appreciate the fire’s dance, and the minimal design ensures all attention is on the glow within.

Operation is intuitive: a single lever regulates all airflow — primary, secondary, and post-combustion — giving you fine control over burn rate without complexity. Behind the scenes, the combustion system is engineered for efficient performance, reducing emissions and maximizing heat. For contemporary, tightly sealed homes, the 16-Up model supports an outside air connection to draw combustion air externally and maintain indoor air quality.


🔥 Key Features & Benefits

  • Elevated firebox design — positions the flames higher for dramatic effect

  • Large log compatibility — accepts logs up to ~60 cm in length

  • Wide panoramic viewing — expansive glass for full flame immersion

  • Sleek, understated styling — no exposed handles or vents

  • Single-lever control — intuitive regulation of all airflow paths

  • Efficient combustion technology — cleaner, hotter, more efficient burns

  • Outside air ready — supports ducting in sealed homes

Spec Value
Log length ~ 60 cm
Nominal output ~ 11–13 kW
Maximum output ~ 18–22 kW
Efficiency ~ 65–70 %
Particle emissions ~ 3.0 g/h
Heating coverage Up to ~ 200 m²
Smoke duct / flue Ø 180 mm
Outside air inlet Ø 63 mm
Approx. weight ~ 160 kg
Overall dimensions (W × H × D) ~ 780 × 1,300 × 460 mm (including base)

🛠 Installation & Use Notes

  • Must operate with the door closed to maintain proper airflow and combustion control.

  • Mounting surface must support the combined weight of stove and stored wood.

  • For airtight homes, the outside air connection is highly recommended to avoid drawing from the living space.

  • Use seasoned hardwood for optimal performance — clean flame, minimal smoke, high efficiency.

  • Routine maintenance and flue sweeping are essential for safe, consistent operation.


🌟 Why Choose Hot Box Stoves for Your Stûv Stove?

At Hot Box Stoves, we bring over a decade of expertise in supplying and installing premium stuv wood burning stoves. When you work with us, you benefit from:

  • Clear, informed guidance to help you select the perfect stove model

  • Free, no-obligation quotes with transparent pricing

  • Fully insured, HETAS-qualified engineers for safe and reliable installation

  • Ongoing warranty and aftercare support

  • A carefully curated collection of high-quality stoves and accessories

  • Reliable, supportive service from purchase through installation

Your Stûv 16-Up 16/78 isn’t just a heating appliance — it’s a design centerpiece. With Hot Box Stoves, it’s backed by knowledge, experience, and a commitment to excellence.

Weight 160 kg
Dimensions 78 × 130 × 46 cm

Reviews

There are no reviews yet.

Be the first to review “Stuv 16-up 16/78 Wood Burning Stove”

Stuv 16-up 16/78 Wood Burning Stove Technical Details

Every Stûv stove installed by Hot Box Stoves is fitted to the highest industry standards, ensuring optimal performance, safety, and efficiency. Our installation team is fully trained in Stûv’s technical requirements, including correct flue sizing, ventilation provision, and heat output calculations. We use only manufacturer-approved components and follow HETAS regulations to guarantee compliance. Technical specifications such as dimensions, kW output, fuel type compatibility, and flue configuration are provided with every quotation to ensure your chosen model is perfectly matched to your property.

Height 46 CM


Width 130 CM


Depth 78 CM


Weight 160 KG

Warranty Details

Every Stûv stove is backed by the official 5/3/3 Guarantee, giving you complete peace of mind.

5 years on the stove body


3 years on original electrical components


3 years on other components (base grate, door mechanism, hinges etc)
